Speaker Presonus รุ่น CDL12P

Speaker Presonus รุ่น CDL12P


PreSonus CDL12 ตู้ลำโพงไลน์อาร์เรย์ 2 ทาง ขนาด 12 นิ้ว 2,000 วัตต์ มีแอมป์ในตัว


A unique look with a unique result

Each CDL12 consists of eight 2-inch drivers aligned in a segmented circular-arc high-frequency array centered in front of a 12-inch woofer. The output of the low-frequency driver travels from the same acoustic axis as the high-frequency array so that the pattern always radiates from the center of the CDL12. This is true whether the CDL12 is used individually on a tripod speaker stand or as part of an acoustically coupled vertical array with up to six enclosures. Because of this, the CDL12 avoids the near-field anomalies that can interfere with the sound quality of a traditional line array. This makes the CDL12 ideally suited for a broader range of venue sizes, creating a far-field response almost immediately as the sound is projected from the center of the enclosure.



Symmetrical dispersion matters.

Traditional line array loudspeakers typically place a high-frequency horn on one side of the enclosure and a woofer on the other. To obtain a symmetrical image with those loudspeakers, you'd have to flip one over—something they aren't designed to do in the first place—and you'd still have phase issues. With the CDL12, the eight 2-inch high-frequency drivers arc over a single 12-inch woofer, comparable to the coaxial driver configuration found on top studio monitors. The result is better sonic coherence across the entire venue, with no anomalies to compensate for via time-consuming room correction. Regardless of how many CDL12s you stack, you're working with a shared acoustic axis—and non-turbulent sound propagating throughout the room.



Scalable vertical coverage.

The CDL12’s hybrid point source/line array design delivers focused sound with consistent SPL coverage both on- or off-axis, making it an excellent choice for mobile and installed applications. Rigging CDL12 enclosures is made easier, thanks to integrated pin-loaded rigging hardware. A dual-angle pole mount is provided, supporting the use of one or two enclosures when pole mounted on a tripod stand, or atop the companion CDL18s subwoofer, allowing the system to adapt to varying audience sizes. When vertically arrayed for suspended applications, up to five CDL12 enclosures can be flown beneath one or two CDL18s subwoofers. When flown without a subwoofer, six CDL12 loudspeakers can be arrayed to create a truly symmetric 120˚ x 120˚ design.



Onboard processing power.

The CDL12’s integrated PDA-1000 500W x 500W Class D power amplifier features onboard DSP presets to facilitate and simplify arrayed configurations. For more advanced applications, each CDL12 can be connected to a standard LAN network and remotely controlled using Worx Control software for macOS® and Windows®. When combined with the CDL12, Worx Control provides speaker-management tools that include compression, limiting, and 800 ms of delay. An 8-band EQ with individually selectable filters (High Pass, Low Pass, High Shelf, Low Shelf, Notch, All Pass, Band Pass) is also provided to compensate for room anomalies. Speakers can be grouped and managed individually or together. Performance monitoring indicators allow you to monitor temperature and signal levels remotely.



Dante® spoken here.

The locking Ethernet connection on the CDL12’s integrated PDA-1000 power amplifier also provides audio networking capability via Dante. Dante’s multi-channel digital media networking technology delivers near-zero latency and synchronization and has been adopted by many pro-audio manufacturers, facilitating the CDL12 loudspeaker’s interoperability with a wide range of equipment.



Specifications

Acoustic Performance

Configuration
Active 2-way
Frequency Response (-3 dB)
48 Hz – 18 kHz
Frequency Response (-10 dB)
42 Hz – 19 kHz
Nominal Coverage (-6 dB)
120° x 20° per enclosure
Maximum Peak SPL
131 dB
Crossover Frequency
420 Hz

LF Transducer
12” (2.5” voice coil)
HF Transducer
8 x 2” (1” Voice Coil)



Amplifier

Type
Class D
Total Power Output
2000W Peak, 1000W Program (500W RMS)
LF Power
1000W Peak, 500W Program (250W RMS)
HF Power
1000W Peak, 500W Program (250W RMS)
Cooling
Free air convection
Rated THD
<0.05% (20 Hz - 20 kHz)
Dynamic Range
119 dB (A-weighted)
Bandwidth
20 Hz - 20 kHz
Mains Connection
powerCON™ In and Out



Connections and Controls

Input Channels
1 Line
Input Connector Types
1 XLR
Line Input Impedance
40 kΩ
Maximum Input
+4 dBu
Output Connector
Direct Line Out (XLR)
Networking
Dante® (Audio and Control), Control (only) via Locking Ethernet
Controls
Preset Select
HPF On/Off
Indicators
Over Temperature, Signal, -3 dB, Limiter, Clip, Network Status



DSP

Effects
Compression, Limiting, Delay, 8-band EQ and preset selection via WorxControl
HPF
90 Hz, 4th-order Butterworth
Bit Depth
24-bit
Sample Rate
48 kHz



Enclosure

Material
15 mm Eucalyptus plywood
Finish
Chemline™ Polyurea
Grille
Powder-coated steel
Dimensions (HxWxD)
18.6” x 20.8” x 17.5” (473 mm x 529 mm x 444.5 mm)
Unit Weight
65 lbs. (29.5 kg)



Safety

Amplifier Protection
Over-current, DC, over/under-voltage, over-temperature, high frequency
Transducer Protection

Power

AC Power Input
90-260V~, 50-60 Hz
AC Power Consumption (1/8 Power)
4.2 Amps
Suspension Mounting

Rigging Points
Integrated Rigging (10:1 load)
Mounting
Dual-position pole mount (0° and 10°) 35 mm
Optional Accessories

Rigging
CDL Rigging Grid, CDL Rigging Extension Bar, CDL Rigging Sling
Other
CDL12-Tote Tote Bag
